Kranman 30-60 is a smooth and light crane that requires little oil flow. The price includes the grapple, rotator and 6-lever valve package. Gate and support legs are added to the price.
Crane 30-60
Art. no K30-60
Specification
| Length | 4.4 m |
| Lifting force 1.2m | 500 kg |
| Lifting force 3 m | 240 kg |
| Gripper | 0,8 m² |
| Extend | 0.9m |
| System pressure | 180 bar |
| Weight | 302 kg incl. gate, support legs and grapple |
| Weight | 232 kg incl. gripper and rotator |
| Recommended oil flow | 10-25 l/min |
